#403

GP 42 Zurich

SOLD

GENERAL
Name
GP 42 Zurich
Model
GP 42
Year
2007
Hull material
Carbon
Color hull
black
Located
Barcelona
Price
PRICE AT REQUEST
VAT
NOT PAID
Flag
spanish
Type
RACER
Slogan
The real sailing speed within your reach!!!!
Description
The real sailing speed within your reach!!!!
DESIGN
    Builder
    King Marine
    Designer
    Botin & Carkeek
DIMENSIONS
    LOA
    13.00m
    Beam
    3,875m
    Draft
    2,60m
    Displacement
    4205kg
ENGINES
    Engines
    Yanmar. HP: 29
    Propeller
    Gori 420 racing.
TANKS
    Fuel
    65 l.l
    Water
    2 Flexible tanks.l
ACCOMMODATIONS
    Shower
    Yes
ELECTRICAL
    Electrical notes
    Halogen lighting; two 100 Ah batteries; 80 Amp alternator; 12 V distribution panel, circuit breakers
SPARS & RIGGING
    Sails
    mainsail 1 4 jibs 3 asymetrical Stysail Mainsail 2 (2 races) 2 jibs 1 asymetrical Storm jib + trysail
    Mast
    Carbon mast
    Spars and rigging notes
    Carbon Hall Spar, 2 spreaders, 2 carbon jockey pole; carbon spinnaker pole; Rod rigging by Navtec Series 800; Tuff luff; mast jack + plates.
DECK EQUIPMENT
    Winches
    Harken: Primaries 530 TCR; cockpit 50STQR; mainsheet 50,2 STR; backestay 45 STR; Harken carbon pedestal for primaries; 6 handless.
    Deck equipment notes
    Steering: carbon tiller. Deck color: white. Harken, Spinlock.
CONSTRUCTION
    Keel
    700 Mpa steel
    Construction notes
    Hull Identification: serial number 2. Internal system to control jib track, mainsail sheet, outhaul, main traveler. Good bottom finished; epoxy 545 done again at december 2008. Light weight; combination of wood trimming with carbon in-lay on entrance steps, engine box, sole, chart area, etc.
FINAL NOTES
    Final notes
    Model: saildrive. Female moulds for hull and deck; carbon clear finish for hull; minimum use of filler to minimize weight; special bottom finished by crew using 1200 water paper. Spares & Other Features: Full set of ropes; 2 life rafts; 10 inflatable life jackets; flares, etc. Special cradle with two positions
