Owners manual and CE certificates, A Ocean by GL (Germanischer Lloyd).
DIMENSIONS
LOA
13.00m
Beam
3.82m
Draft
2.5m
Displacement
6500kg
ENGINES
Engines
Yanmar 30HP
Propeller
Racing two-blade folding propeller
TANKS
Fuel
Fuel oil tank with a total capacity of app. 86 l under the seat bench (saloon)l
Water
Ventilated fresh water tank for a total capacity of app. 120 l l
Holding
Waste holding tank (app. 40 l) fitted with tank level watchl
ACCOMMODATIONS
Shower
Yes
GALLEY
Refrigerator
WAECO C 50 refrigerator
Water system
a mixing tap for ho t& cold fresh water pressurized
Galley notes
U-shaped
twin sinks in basalt FRP;
Worktops in basalt
a covered gas stove (on gimbals) oven and three burners
storage lockers with shelves and doors, storage with shelve and door placed below the sinks.
NAVIGATION INSTRUMENTS
Electronics
Raymarine ST 60 equipment, speed depth
VHF
VHF Raymarine
Automatic pilot
Raymarine Autopilot ST 6001
Compass
Magnetic compass fitted on the GRP steering pedestal
Plotter
Raymarine E80 Chartplotter GPS
Navigation instruments notes
3 x Maxi repeater from Tack Tick on mast bracket and remote control
AIS transponder
ELECTRICAL
Batteries
1 x 12V 100 Ah engine start battery, 1 x 12V 170 Ah service battery
Battery charger
Quick battery charger 12V 30A
Electrical notes
12 V DC SYSTEM
12 V sockets
shore power dock side cable
navigation lights (bow port, bow stbd,stern), running light, anchor&tricolor light,deck light.
alternator 60A/12V
SPARS & RIGGING
Sails
Quantum sails (used one season)
Fusion M IRC: mainsail + Jib Code 1 to 4
Masttop gennaker R-1
Masttop spi S-2
Masttop spi S-4 (2x of which one 1/2 year old)
Staysail
Code 0
Fractional spi S2 (ORC) half a year old
Fusion X mainsail
Code 2
Code 5
Trysail, stormjib
Mast
Nordic high modulus carbon mast fractional and tapered, painted- off white and double swept back spr
Spinnaker pole
carbon spi pole
Spars and rigging notes
Carbon bowsprit / prod for A symmetric/code 0
carbo foil by Harken on forestay
adjustable spinnaker pole track
windex wind indicator
Nordic boom in carbon with two reef lines, one outhaul 8:1.
gas pressured boom vang with an outer purchase block system.
Discontinuous rod rigging with Nordic tipcups.
Carbon magic wheel for backstay
hydraulic mast jack
self-draining anchor/chain locker which includes stowage for fenders and mooring ropes
Cockpit with 8 mm teak ribs/massive on cockpit seats
two storage lockers in mid cockpit, outboard drained gas bottle (port) compartment
GRP steering pedestal with compass
Harken main sheet track (1 x 1,8 m) on the cockpit sole, 6:1 traveller
Harken genoa sheet tracks (2 x 3,6 m), 5:1
2xgenoa car systems with ball bearings.
Blocks Racing (by Harken)
Mainsheet system (German) Black Magic Harken
Jefa Racing steering wheel, aluminum 52
carbon rudder on the carbon stock
Harken genoa sheet tracks (2 x 3,6 m), 5:1
2xgenoa car systems with ball bearings.
Blocks (by Harken)
Mainsheet system (German) Black Magic Harken
Jefa steering wheel, aluminum 52
carbon rudder on the carbon stock.
SAFETY EQUIPMENT
Fire-extinguishers
2
Safety equipment notes
Emergency tiller in stainless steel
electric bilge selfpriming membrane pump for the central bilge, electric bilge pump for the aft bilge,
Manually operated bilge pump in the cockpit.
CONSTRUCTION
Keel
ORC int or IRC keel, 2.5m long,; a nodular cast fin with the lead bulb coated with epoxy protection.
Construction notes
Material: Vinylester
Vacuum infused epoxy based vinylester Hull & Deck
Shakewell flush racing seacocks
EXTRA
Swimming ladder
Yes
Extra notes
Aluminium Fortress anchor with leadline
racing floor foam/basalt carbon
FINAL NOTES
Final notes
Disclaimer
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
